110-170GHz, WR-6, 25dBi Gain, BGL625A_P0 Standard Gain Horn Antenna SKU: BGL625A_P0 Frequency(GHz): 110-170 Waveguide Size EIA WR: WR6 Gain, Typ (dBi): 25 Polarization: Linear 3dB Beamwidth, E-Plane, Typ (Deg.): 9 3dB Beamwidth, H-Plane, Typ (Deg.): 10 Cross Pol. Isolation, Typ (dB): 35 VSWR, Typ: 1.15:1 Output : UG-387/U Body Material: Cu Finish: Gold Plated Size, W (inch): 0.75 SSize, H (inch): 0.75 Size, L ((inch): 1.61 Weight, (lb): 0.044 Add to WishlistRemove from Wishlist Add to Wishlist Product Detail Reviews (0) Reviews There are no reviews yet. Be the first to review “110-170GHz, WR-6, 25dBi Gain, BGL625A_P0 Standard Gain Horn Antenna” Cancel replyYour email address will not be published. Required fields are marked *Your rating Rate… Perfect Good Average Not that bad Very poor Your review *Name * Email * Save my name, email, and website in this browser for the next time I comment. Δ Related Products 6-18GHz, 10dBi Gain, KBL618NF Broadband Horn Antenna 0 out of 5 170-260GHz, WR-4, 25dBi Gain. BGL425A_P0 Standard Gain Horn Antenna 0 out of 5 325-500GHz, WR-2.2, 25dBi Gain, BGL2.225A_P0 Standard Gain Horn Antenna 0 out of 5 Hot Products 110-170GHz, WR-6, 25dBi Gain, BGL625A_P0 Standard Gain Horn Antenna 0 out of 5 6-18GHz, 10dBi Gain, KBL618NF Broadband Horn Antenna 0 out of 5 170-260GHz, WR-4, 25dBi Gain. BGL425A_P0 Standard Gain Horn Antenna 0 out of 5 325-500GHz, WR-2.2, 25dBi Gain, BGL2.225A_P0 Standard Gain Horn Antenna 0 out of 5
